| Housing | Anodized aluminum |
| Dimensions | 287x137x49 mm |
| Weight | 3.25 kg |
| Speed | max. 12 m/min |
| Operating temperature | --- |
| Waterproof / Water depth | 5 bar / 50 m |
| Accessories | --- |
| Features | - Inspection camera in front of or on the trolley - Rear camera - Rear lighting Various magnetic hoops/chains available |
VT 34 MFW - magnetic crawler
Compact, extremely maneuverable magnetic crawler with adaptable VT 34 PT pan-tilt camera in the front of the vehicle and additional camera at the rear of the vehicle.
- High-quality and particularly reliable magnetic crawler thanks to robust housing and easy handling
- Integrated inspection camera with light and pan and tilt function
- Integrated rear view camera for reversing
- Strong built-in magnets for vertical and horizontal maneuvering
Product overview
The integrated lighting guarantees excellent illumination of the object. Magnetic wheels or a magnetic chain drive enable driving of vertical and perpendicular walls or ceilings.
Do you need the right equipment to investigate in nuclear or industrial environments, even dark or hard-to-reach places? Our waterproof powerful magnetic crawler offers the optimal solution: Thanks to a resistant housing and robust electronics, this crawler is suitable for long-term operation and can be used in the smallest of spaces.
Key features
- Universal platform
- Modular structure
- Robust construction (anodized aluminum housing)
- Available with magnetic wheels or magnetic chain drive
- Waterproof up to 5 bar
Documents
Areas of application
Offshore
Storage pool inspection (nuclear power plant)
Reactor inspection
Pipeline inspection
Tank inspection
